一种用于钛合金零件激光快速成形的可控气氛保护装置

本发明公开了一种用于钛合金零件激光快速成形的可控气氛保护装置，该装置由

刚性密封箱体和柔性囊式密封罩构成，刚性密封箱体上设有充气口、排气口，充气口和排气口上分别设有阀门；该装置在抽气过程中，腔内空气随排气口被抽出，柔性囊式密封罩在负压作用下将逐渐与刚性密封箱体的内壁、腔底靠近并最终紧密贴合于刚性密封箱体的内壁、腔底，达到排出腔内全部空气；随后关闭抽气口上的阀门，打开充气口上阀门充入所需保护气体，在充入保护气体过程中，柔性囊式密封罩随之升高充涨，使腔内形成所需的保护气氛状态；所述柔性囊式密封罩的厚度为0 .1mm～100mm；所述刚性密封箱体的厚度为0 .5mm～2m。

Controllable atmosphere protection device for laser rapid forming of titanium alloy parts

The invention discloses a controllable atmosphere protection device for laser rapid forming of titanium alloy parts. The controllable atmosphere protection device is constituted by a rigid sealing box and a flexible capsule-type sealing cover; and the rigid sealing box is provided with an inflating opening and an exhaust opening, and valves are arranged on the inflating opening and the exhaust opening correspondingly. According to the controllable atmosphere protection device, in the air pumping process, air in a cavity is pumped out along with the exhaust opening, the flexible capsule-type sealing cover gradually gets close to the inner wall and the cavity bottom of the rigid sealing box under the negative pressure action and finally attaches to the inner wall and the cavity bottom of the rigid sealing box closely, and thus all the air in the cavity is fully exhausted; then a valve in an air pumping opening is closed, the valve in the inflating opening is opened and filled with required protection gas, in the process of filling the protection gas, the flexible capsule-type sealing cover rises and is swelled in a following mode, and thus a required protection atmosphere state is formed in the cavity; the thickness of the flexible capsule-type sealing cover is 0.1mm-100mm; and the thickness of the rigid sealing box is 0.5mm-2m.
